ElmasonicEasy

Overview Technical specifications Accessories

ElmasonicEasy

Intuitive operation

with LED displays and practical rotary control

Dynamic & Eco Mode

maximum performance or quiet operation with reduced energy consumption

Safety as standard

Automatic shut-off

Perfect fit

on Elma accessories & chemicals

Elmasonic Easy is the straightforward entry into professional ultrasonic cleaning – compact, powerful, and intuitive to use. With clear functionality, modern design, and optional heating function, it offers everything you need for daily use. Whether in the laboratory, workshop, or jewelry studio, the Easy series offers easy handling, useful accessories, and excellent value for money – ultrasonic cleaning as it should be: simply effective.

The operating modes

Dynamic Mode

Achieving an optimal blend of powerful cleaning effectiveness and homogeneously distributed mechanical cleaning action.

Eco Mode

Gentle cleaning that is remarkably quiet and energy-efficient, ensuring a longer appliance life.

Elmasonic Easy

Heating Power

Model Size

Informations
Informations	0.7 l	240 W	W
External dimensions
External dimensions	235 mm	130 mm	200 mm
Internal dimensions
Internal dimensions	185 mm	80 mm	55 mm

€315

excl. VAT plus shipping

Description

Elmasonic Easy is an ultrasonic device for simple applications in a wide range of areas. It is characterized by its simple operation while still offering proven Elma quality. While eco mode enables energy-efficient and noise-reduced operation, dynamic mode provides full power with uniform sound field distribution. With the optionally available modular basket system, the Elmasonic Easy also offers significantly more flexibility than devices with classic wire mesh baskets.

Scope of Delivery

Plastic lid
Power cord (2 m long)
Operating instructions
Hose nozzle for drainage (from 60H)

Note: Cleaning baskets and other accessories are available as optional extras. Items to be cleaned must not be placed directly on the bottom of the tub, as this may cause damage.

Downloads

Elmasonic Easy Brochure EN
(PDF, 1.97 MB)
Elmasonic Easy Manual EN
(PDF, 2.02 MB)

Model Variant	10	10H	20	20H	30	30H	40H	60H	100H	120H	180H	300H
Model Variant	Item number EU 220 - 240 ~V	Item number CH 220 - 240 ~V	Item number UK 220 - 240 ~V	List Price €	Mechanics	Recommended tank operating capacity l	Recommended Working Volume l	External Dimensions mm	Interior Dimensions mm	Weight kg	Drain Thread	Electrical and Noise level	Mains Voltage ± 10 % V	Mains Frequency Hz	Ultrasonic Frequency -2,5 / +5,5 kHz	Total Power Consumption W	Ultrasonic Power eff. ± 10% W	Ultrasonic Peak Power W	Heating Power W	Temperature °C	Safety Class	Sound pressure level (LpAU)* db(A)
Item number EU 220 - 240 ~V	1118881-001	1118883-001	1118885-001	1118887-001	1118889-001	1117697-001	1118892-001	1118894-001	1118896-001	1118898-001	1118900-001	1118902-001
Item number CH 220 - 240 ~V	1118881-002	1118883-002	1118885-002	1118887-002	1118889-002	1117697-002	1118892-002	1118894-002	1118896-002	1118898-002	1118900-002	1118902-002
Item number UK 220 - 240 ~V	1118881-003	1118883-003	1118885-003	1118887-003	1118889-003	1117697-003	1118892-003	1118894-003	1118896-003	1118898-003	1118900-003	1118902-003
List Price €	315 €	380 €	375 €	450 €	430 €	480 €	710 €	830 €	990 €	1.290 €	1.400 €	1.760 €
Mechanics
Recommended tank operating capacity l	0,9	0,9	1,6	1,6	2,7	2,7	3,9	5,9	9,5	12,9	17,8	27,5
Recommended Working Volume l	0,7	0,7	1,2	1,2	1,6	1,6	2,9	4,3	6,8	10	14,2	22
External Dimensions mm	235 × 130 × 200	235 × 130 × 200	215 × 190 × 230	215 × 190 × 230	305 × 190 × 230	305 × 190 × 230	305 × 190 × 280	370 × 225 × 280	380 × 315 × 280	380 × 315 × 330	405 × 375 × 330	575 × 375 × 330
Interior Dimensions mm	185 × 80 × 55	185 × 80 × 55	140 × 125 × 95	140 × 125 × 95	220 × 120 × 95	220 × 120 × 95	215 × 115 × 145	280 × 130 × 145	280 × 220 × 145	275 × 215 × 195	300 × 270 × 195	475 × 270 × 195
Weight kg	2,2	2,2	2,6	2,6	3,3	3,3	4	5,1	5,9	7,8	8,7	11,5
Drain Thread	–	–	–	–	–	–	–	G 3/8	G 3/8	G 3/8	G 3/8	G 3/8
Electrical and Noise level
Mains Voltage ± 10 % V	EU 220 - 240 ~V CH 220 - 240 ~V UK 220 - 240 ~V EU 220 - 240 ~V	EU 220 - 240 ~V CH 220 - 240 ~V UK 220 - 240 ~V	EU 220 - 240 ~V CH 220 - 240 ~V UK 220 - 240 ~V	EU 220 - 240 ~V CH 220 - 240 ~V UK 220 - 240 ~V	EU 220 - 240 ~V CH 220 - 240 ~V UK 220 - 240 ~V	EU 220 - 240 ~V CH 220 - 240 ~V UK 220 - 240 ~V	EU 220 - 240 ~V CH 220 - 240 ~V UK 220 - 240 ~V	EU 220 - 240 ~V CH 220 - 240 ~V UK 220 - 240 ~V	EU 220 - 240 ~V CH 220 - 240 ~V UK 220 - 240 ~V	EU 220 - 240 ~V CH 220 - 240 ~V UK 220 - 240 ~V	EU 220 - 240 ~V CH 220 - 240 ~V UK 220 - 240 ~V	EU 220 - 240 ~V CH 220 - 240 ~V UK 220 - 240 ~V
Mains Frequency Hz	50 / 60	50 / 60	50 / 60	50 / 60	50 / 60	50 / 60	50 / 60	50 / 60	50 / 60	50 / 60	50 / 60	50 / 60
Ultrasonic Frequency -2,5 / +5,5 kHz	37	37	37	37	37	37	37	37	37	37	37	37
Total Power Consumption W	30	90	35	155	80	280	320	550	550	1.000	1.000	1.500
Ultrasonic Power eff. ± 10% W	30	30	35	35	80	80	120	150	150	200	200	300
Ultrasonic Peak Power W	240	240	280	280	320	320	480	600	600	800	800	1.200
Heating Power W	–	60	–	120	–	200	200	400	400	800	800	1.200
Temperature °C	–	25 – 80	–	25 – 80	–	25 – 80	25 – 80	25 – 80	25 – 80	25 – 80	25 – 80	25 – 80
Safety Class	IP 20	IP 20	IP 20	IP 20	IP 20	IP 20	IP 20	IP 20	IP 20	IP 20	IP 20	IP 20
Sound pressure level (LpAU)* db(A)	–	–	–	–	–	–	–	–	–	–	–	–
10	1118881-001	1118881-002	1118881-003	315 €		0,9	0,7	235 × 130 × 200	185 × 80 × 55	2,2	–		EU 220 - 240 ~V CH 220 - 240 ~V UK 220 - 240 ~V EU 220 - 240 ~V	50 / 60	37	30	30	240	–	–	IP 20	–
10H	1118883-001	1118883-002	1118883-003	380 €		0,9	0,7	235 × 130 × 200	185 × 80 × 55	2,2	–		EU 220 - 240 ~V CH 220 - 240 ~V UK 220 - 240 ~V	50 / 60	37	90	30	240	60	25 – 80	IP 20	–
20	1118885-001	1118885-002	1118885-003	375 €		1,6	1,2	215 × 190 × 230	140 × 125 × 95	2,6	–		EU 220 - 240 ~V CH 220 - 240 ~V UK 220 - 240 ~V	50 / 60	37	35	35	280	–	–	IP 20	–
20H	1118887-001	1118887-002	1118887-003	450 €		1,6	1,2	215 × 190 × 230	140 × 125 × 95	2,6	–		EU 220 - 240 ~V CH 220 - 240 ~V UK 220 - 240 ~V	50 / 60	37	155	35	280	120	25 – 80	IP 20	–
30	1118889-001	1118889-002	1118889-003	430 €		2,7	1,6	305 × 190 × 230	220 × 120 × 95	3,3	–		EU 220 - 240 ~V CH 220 - 240 ~V UK 220 - 240 ~V	50 / 60	37	80	80	320	–	–	IP 20	–
30H	1117697-001	1117697-002	1117697-003	480 €		2,7	1,6	305 × 190 × 230	220 × 120 × 95	3,3	–		EU 220 - 240 ~V CH 220 - 240 ~V UK 220 - 240 ~V	50 / 60	37	280	80	320	200	25 – 80	IP 20	–
40H	1118892-001	1118892-002	1118892-003	710 €		3,9	2,9	305 × 190 × 280	215 × 115 × 145	4	–		EU 220 - 240 ~V CH 220 - 240 ~V UK 220 - 240 ~V	50 / 60	37	320	120	480	200	25 – 80	IP 20	–
60H	1118894-001	1118894-002	1118894-003	830 €		5,9	4,3	370 × 225 × 280	280 × 130 × 145	5,1	G 3/8		EU 220 - 240 ~V CH 220 - 240 ~V UK 220 - 240 ~V	50 / 60	37	550	150	600	400	25 – 80	IP 20	–
100H	1118896-001	1118896-002	1118896-003	990 €		9,5	6,8	380 × 315 × 280	280 × 220 × 145	5,9	G 3/8		EU 220 - 240 ~V CH 220 - 240 ~V UK 220 - 240 ~V	50 / 60	37	550	150	600	400	25 – 80	IP 20	–
120H	1118898-001	1118898-002	1118898-003	1.290 €		12,9	10	380 × 315 × 330	275 × 215 × 195	7,8	G 3/8		EU 220 - 240 ~V CH 220 - 240 ~V UK 220 - 240 ~V	50 / 60	37	1.000	200	800	800	25 – 80	IP 20	–
180H	1118900-001	1118900-002	1118900-003	1.400 €		17,8	14,2	405 × 375 × 330	300 × 270 × 195	8,7	G 3/8		EU 220 - 240 ~V CH 220 - 240 ~V UK 220 - 240 ~V	50 / 60	37	1.000	200	800	800	25 – 80	IP 20	–
300H	1118902-001	1118902-002	1118902-003	1.760 €		27,5	22	575 × 375 × 330	475 × 270 × 195	11,5	G 3/8		EU 220 - 240 ~V CH 220 - 240 ~V UK 220 - 240 ~V	50 / 60	37	1.500	300	1.200	1.200	25 – 80	IP 20	–

Individual consultation

Our experts will assist you in selecting and combining the right equipment, accessories, and chemicals for your requirements.

Request rental equipment

Rent a device as a replacement while your device is being repaired by Elma or to test it for your application.

Start cleaning test

We test your components under real conditions - so you can make confident decisions.
