Elmasteam8 basic

Overview Technical specifications Accessories

Elmasteam8 basic

Cleaning, rinsing and drying -

all with one device

Individually control steam

for 4–8 bar applications and from wet to dry steam

Environmentally friendly technology

for precise and gentle cleaning

High quality & reliability

with a 3-year warranty

Elmasteam 8 basic combines cleaning, rinsing, and drying in one device – powerful, flexible, and easy to maintain. With up to 8 bar steam pressure, adjustable water content in the steam, and practical cleaning functions, the device is ideal for demanding applications in workshops, production, and jewelry processing—efficient, chemical-free, and with well-designed accessories.

Elmasteam 8 basic

Usage

Informations
Informations	8 bar	< 160 °C
External Dimensions
External Dimensions	360 mm	355 mm	520 mm

Integrated Pump

Compressed Air Connection

Available immediately. Shipping time: 3-5 business days.

€2,240

excl. VAT plus shipping

Description

The Elmasteam 8 basic combines cleaning, rinsing, and drying in one compact device and, with 8 bar steam pressure, offers powerful support for demanding cleaning tasks. Thanks to selectable “Soft” and “Strong” pressure modes and an adjustable steam ratio, different materials can be cleaned particularly gently and at the same time in an environmentally friendly manner. In Eco mode, the device operates in an energy-saving manner, while the optional compressed air function enables quick blowing off and efficient drying of workpieces.

Scope of delivery

Maintenance Tube, Filling Sieve, Flushing set, Tweezer
3 O-rings
2 Test strips each for determine water hardness and chloride content
3 packets Elma Steam Descaler (á 45g)
Power cable with rubber connector (2 m length)
Manual

Downloads

Elmasteam 8 basic Brochure EN
(PDF, 421.18 KB)
Elmasteam 8 basic Manual EN
(PDF, 2.46 MB)

Model Variant	FD	HS	HS - FD	P - FD - DL	P - HS - DL	P - HS - DL - ND	P - HS - FD - DL	P - HSL - DL	P - HSL - DL - ND
Model Variant	Item number EU 220 - 240 ~V	Item number CH 220 - 240 ~V	Item number UK 220 - 240 ~V	Price €	Mechanics	Has Fixed Nozzle	Has Handpiece	Hose length Handpiece m	Has Integrated Pump	Has Wet Steam	Has Compressed Air Connection	Max. working pressure bar	Pressure vessel capacity l	Max. filling volume l	External Dimensions incl. mounted partsmm	Weight kg	Electrical and Noise level	Mains Voltage ± 10 % V	Mains Frequency Hz	Total Power Consumption W	Steam temperature Pressure vessel °C	Pressure vessel volume °C	Sound pressure level at 8 bar dB(A)
Item number EU 220 - 240 ~V	1075995-001	1075955-001	1075988-001	1076002-001	1075958-001	1075959-001	1075961-001	1090868-001	1119627-020
Item number CH 220 - 240 ~V	1075995-002	1075955-002	1075988-002	1076002-002	1075958-002	1075959-002	1075961-002	1090868-002	1119627-002
Item number UK 220 - 240 ~V	1075995-003	1075955-003	1075988-003	1076002-003	1075958-003	1075959-003	1075961-003	1090868-003	1119627-003
Price €	2.240 €	2.520 €	2.780 €	3.000 €	3.300 €	3.530 €	3.590 €	3.380 €	3.660 €
Mechanics
Has Fixed Nozzle	•		•	•			•
Has Handpiece		•	•		•	•	•	•	•
Hose length Handpiece m	–	1,4	1,4	–	1,4	1,4	1,4	2,3	2,3
Has Integrated Pump				•	•	•	•	•	•
Has Wet Steam						•			•
Has Compressed Air Connection				•	•	•	•	•	•
Max. working pressure bar	8	8	8	8	8	8	8	8	8
Pressure vessel capacity l	5	5	5	5	5	5	5	5	5
Max. filling volume l	3,8	3,8	3,8	3,8	3,8	3,8	3,8	3,8	3,8
External Dimensions incl. mounted parts mm	360 × 355 × 520	315 × 350 × 520	315 × 355 × 520	260 × 355 × 520	315 × 350 × 520	315 × 350 × 520	315 × 355 × 520	315 × 350 × 520	315 × 350 × 520
Weight kg	20	20	20	20	20	20	20	20	20
Electrical and Noise level
Mains Voltage ± 10 % V	EU 220 - 240 ~V CH 220 - 240 ~V UK 220 - 240 ~V	EU 220 - 240 ~V CH 220 - 240 ~V UK 220 - 240 ~V	EU 220 - 240 ~V CH 220 - 240 ~V UK 220 - 240 ~V	EU 220 - 240 ~V CH 220 - 240 ~V UK 220 - 240 ~V	CH 220 - 240 ~V UK 220 - 240 ~V EU 220 - 240 ~V	CH 220 - 240 ~V UK 220 - 240 ~V EU 220 - 240 ~V	CH 220 - 240 ~V UK 220 - 240 ~V EU 220 - 240 ~V	EU 220 - 240 ~V CH 220 - 240 ~V UK 220 - 240 ~V	CH 220 - 240 ~V UK 220 - 240 ~V EU 220 - 240 ~V
Mains Frequency Hz	50 / 60	50 / 60	50 / 60	50 / 60	50 / 60	50 / 60	50 / 60	50 / 60	50 / 60
Total Power Consumption W	3.120	3.120	3.120	3.120	3.120	3.120	3.120	3.120	3.120
Steam temperature Pressure vessel °C	185	185	185	185	185	185	185	185	185
Pressure vessel volume °C	160	160	160	160	160	160	160	160	160
Sound pressure level at 8 bar dB(A)	93	93	93	93	93	93	93	93	93
FD	1075995-001	1075995-002	1075995-003	2.240 €		•		–				8	5	3,8	360 × 355 × 520	20		EU 220 - 240 ~V CH 220 - 240 ~V UK 220 - 240 ~V	50 / 60	3.120	185	160	93
HS	1075955-001	1075955-002	1075955-003	2.520 €			•	1,4				8	5	3,8	315 × 350 × 520	20		EU 220 - 240 ~V CH 220 - 240 ~V UK 220 - 240 ~V	50 / 60	3.120	185	160	93
HS - FD	1075988-001	1075988-002	1075988-003	2.780 €		•	•	1,4				8	5	3,8	315 × 355 × 520	20		EU 220 - 240 ~V CH 220 - 240 ~V UK 220 - 240 ~V	50 / 60	3.120	185	160	93
P - FD - DL	1076002-001	1076002-002	1076002-003	3.000 €		•		–	•		•	8	5	3,8	260 × 355 × 520	20		EU 220 - 240 ~V CH 220 - 240 ~V UK 220 - 240 ~V	50 / 60	3.120	185	160	93
P - HS - DL	1075958-001	1075958-002	1075958-003	3.300 €			•	1,4	•		•	8	5	3,8	315 × 350 × 520	20		CH 220 - 240 ~V UK 220 - 240 ~V EU 220 - 240 ~V	50 / 60	3.120	185	160	93
P - HS - DL - ND	1075959-001	1075959-002	1075959-003	3.530 €			•	1,4	•	•	•	8	5	3,8	315 × 350 × 520	20		CH 220 - 240 ~V UK 220 - 240 ~V EU 220 - 240 ~V	50 / 60	3.120	185	160	93
P - HS - FD - DL	1075961-001	1075961-002	1075961-003	3.590 €		•	•	1,4	•		•	8	5	3,8	315 × 355 × 520	20		CH 220 - 240 ~V UK 220 - 240 ~V EU 220 - 240 ~V	50 / 60	3.120	185	160	93
P - HSL - DL	1090868-001	1090868-002	1090868-003	3.380 €			•	2,3	•		•	8	5	3,8	315 × 350 × 520	20		EU 220 - 240 ~V CH 220 - 240 ~V UK 220 - 240 ~V	50 / 60	3.120	185	160	93
P - HSL - DL - ND	1119627-020	1119627-002	1119627-003	3.660 €			•	2,3	•	•	•	8	5	3,8	315 × 350 × 520	20		CH 220 - 240 ~V UK 220 - 240 ~V EU 220 - 240 ~V	50 / 60	3.120	185	160	93

Matching accessories

2mm nozzle for Elmasteam handpiece

Individual consultation

Our experts will assist you in selecting and combining the right equipment, accessories, and chemicals for your requirements.

Request rental equipment

Rent a device as a replacement while your device is being repaired by Elma or to test it for your application.

Start cleaning test

We test your components under real conditions - so you can make confident decisions.

service

The power of steam – Gentle and environmentally friendly.

The origins of Elma – Over 70 years of experience and innovation

Model Variant	FD	HS	HS - FD	P - FD - DL	P - HS - DL	P - HS - DL - ND	P - HS - FD - DL	P - HSL - DL	P - HSL - DL - ND
Item number EU 220 - 240 ~V	1075995-001	1075955-001	1075988-001	1076002-001	1075958-001	1075959-001	1075961-001	1090868-001	1119627-020
Item number CH 220 - 240 ~V	1075995-002	1075955-002	1075988-002	1076002-002	1075958-002	1075959-002	1075961-002	1090868-002	1119627-002
Item number UK 220 - 240 ~V	1075995-003	1075955-003	1075988-003	1076002-003	1075958-003	1075959-003	1075961-003	1090868-003	1119627-003
Price €	2.240 €	2.520 €	2.780 €	3.000 €	3.300 €	3.530 €	3.590 €	3.380 €	3.660 €
Mechanics
Has Fixed Nozzle	•		•	•			•
Has Handpiece		•	•		•	•	•	•	•
Hose length Handpiece m	–	1,4	1,4	–	1,4	1,4	1,4	2,3	2,3
Has Integrated Pump				•	•	•	•	•	•
Has Wet Steam						•			•
Has Compressed Air Connection				•	•	•	•	•	•
Max. working pressure bar	8	8	8	8	8	8	8	8	8
Pressure vessel capacity l	5	5	5	5	5	5	5	5	5
Max. filling volume l	3,8	3,8	3,8	3,8	3,8	3,8	3,8	3,8	3,8
External Dimensions incl. mounted parts mm	360 × 355 × 520	315 × 350 × 520	315 × 355 × 520	260 × 355 × 520	315 × 350 × 520	315 × 350 × 520	315 × 355 × 520	315 × 350 × 520	315 × 350 × 520
Weight kg	20	20	20	20	20	20	20	20	20
Electrical and Noise level
Mains Voltage ± 10 % V	EU 220 - 240 ~V CH 220 - 240 ~V UK 220 - 240 ~V	EU 220 - 240 ~V CH 220 - 240 ~V UK 220 - 240 ~V	EU 220 - 240 ~V CH 220 - 240 ~V UK 220 - 240 ~V	EU 220 - 240 ~V CH 220 - 240 ~V UK 220 - 240 ~V	CH 220 - 240 ~V UK 220 - 240 ~V EU 220 - 240 ~V	CH 220 - 240 ~V UK 220 - 240 ~V EU 220 - 240 ~V	CH 220 - 240 ~V UK 220 - 240 ~V EU 220 - 240 ~V	EU 220 - 240 ~V CH 220 - 240 ~V UK 220 - 240 ~V	CH 220 - 240 ~V UK 220 - 240 ~V EU 220 - 240 ~V
Mains Frequency Hz	50 / 60	50 / 60	50 / 60	50 / 60	50 / 60	50 / 60	50 / 60	50 / 60	50 / 60
Total Power Consumption W	3.120	3.120	3.120	3.120	3.120	3.120	3.120	3.120	3.120
Steam temperature Pressure vessel °C	185	185	185	185	185	185	185	185	185
Pressure vessel volume °C	160	160	160	160	160	160	160	160	160
Sound pressure level at 8 bar dB(A)	93	93	93	93	93	93	93	93	93
FD	1075995-001	1075995-002	1075995-003	2.240 €		•		–				8	5	3,8	360 × 355 × 520	20	EU 220 - 240 ~V CH 220 - 240 ~V UK 220 - 240 ~V	50 / 60	3.120	185	160	93
HS	1075955-001	1075955-002	1075955-003	2.520 €			•	1,4				8	5	3,8	315 × 350 × 520	20	EU 220 - 240 ~V CH 220 - 240 ~V UK 220 - 240 ~V	50 / 60	3.120	185	160	93
HS - FD	1075988-001	1075988-002	1075988-003	2.780 €		•	•	1,4				8	5	3,8	315 × 355 × 520	20	EU 220 - 240 ~V CH 220 - 240 ~V UK 220 - 240 ~V	50 / 60	3.120	185	160	93
P - FD - DL	1076002-001	1076002-002	1076002-003	3.000 €		•		–	•		•	8	5	3,8	260 × 355 × 520	20	EU 220 - 240 ~V CH 220 - 240 ~V UK 220 - 240 ~V	50 / 60	3.120	185	160	93
P - HS - DL	1075958-001	1075958-002	1075958-003	3.300 €			•	1,4	•		•	8	5	3,8	315 × 350 × 520	20	CH 220 - 240 ~V UK 220 - 240 ~V EU 220 - 240 ~V	50 / 60	3.120	185	160	93
P - HS - DL - ND	1075959-001	1075959-002	1075959-003	3.530 €			•	1,4	•	•	•	8	5	3,8	315 × 350 × 520	20	CH 220 - 240 ~V UK 220 - 240 ~V EU 220 - 240 ~V	50 / 60	3.120	185	160	93
P - HS - FD - DL	1075961-001	1075961-002	1075961-003	3.590 €		•	•	1,4	•		•	8	5	3,8	315 × 355 × 520	20	CH 220 - 240 ~V UK 220 - 240 ~V EU 220 - 240 ~V	50 / 60	3.120	185	160	93
P - HSL - DL	1090868-001	1090868-002	1090868-003	3.380 €			•	2,3	•		•	8	5	3,8	315 × 350 × 520	20	EU 220 - 240 ~V CH 220 - 240 ~V UK 220 - 240 ~V	50 / 60	3.120	185	160	93
P - HSL - DL - ND	1119627-020	1119627-002	1119627-003	3.660 €			•	2,3	•	•	•	8	5	3,8	315 × 350 × 520	20	CH 220 - 240 ~V UK 220 - 240 ~V EU 220 - 240 ~V	50 / 60	3.120	185	160	93
